Design features
- Available in carbon fibre composite or hydroformed aluminum with identical geometry, kinematics, and frame features.
- Both frame materials are offered in a range of component specs and price points so riders can choose to prioritize performance where it matters most to them.
- Rear centres and seat tube angles are varied by frame size to ensure consistent rider weight distribution, and short seat tubes with long dropper posts keep the saddle out of the way on technical descents.
Specifications
- SRAM DUB, BSA 73mm, MTB WIDE
- SRAM Maven Base
- SRAM 1270 Eagle T-Type, 10-52T, 12sp
- SRAM Eagle 70 T-type,12sp
- Norco Idler Guide and Lower Guide
- SRAM Eagle S1000, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5)
- Fox 36 Performance Float X2, GripX, HSC/LSC/HSRT/LSR, 160mm, 44mm Offset, Fender Included
- Aluminum Frame, 150mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
- SRAM Maven Base, Metallic Pads
- SRAM HS2, 200mm, 2mm thickness, 6 bolt
- SRAM MTH 716, 15x110mm Boost, 32H, 6-Bolt
- Maxxis Assegai, 3C MaxxGrip new EXO+, 29x2.5", Folding
- WTB Waffle, 140mm Length
- OneUp aluminum, 760mm - 20mm rise (S1), 780mm - 20mm rise (S2), 800mm- 35mm rise (S3,S4,S5)
- FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 )
- SRAM Maven Base, Metallic Pads
- SRAM HS2 180mm, 2mm thickness, 6 bolt
- SRAM Eagle 90 T-Type, 12sp
- SRAM MTH 756, 148x12 Boost, HG, 32H, 6-bolt
- 148mm x 12mm TA, L174, TL13, M12x1.3
- Fox Float X2 Performance Elite, 205x60mm TR
- Maxxis Minion DHR II, 3C Maxx Terra new EXO+, 27.5x2.4", Folding
- Race Face AR30, 32h, 29"-27.5 F/R, 30mm ID
- WTB Solano Med, 142x240 mm
- Stans Tire Sealant, 250 ML
- TranzX YSI160 RAD+, 34.9mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5)
- Norco Alloy Nutted Clamp, 38.5 ID
- SRAM Eagle 90, 12sp
- DT Competition butted 1.8/1.6/1.8 black stainless steel
- OneUp 42mm Length , 35mm Clamp
